Download Pdf Data Sheet: GP Screen TIZIANO TENSIONED
Download Pdf Data Sheet: Projection surfaces
– Silent motor system provides a smooth and quiet operation
· Power: 7 Nm
· Speed: 18 rpm
· Power supply: 230V / 50 Hz
· Consumption: 120 W
· Certification: IMQ
– Totally manufactured with aluminium housing and steel side plates
– Housing dimensions: 167×163 mm. (DxH)
– Housing painted with white epoxy powders (RAL 9016)
– Wall mounting brackets and on/off switcher included
– Ceiling mounting brackets included
– Extremely quiet motor included
– Flame – retardant projection surfaces
– Side black borders of 5 cm. (in the narrowest point), black bottom border of 5 cm., black top drop of 30 cm. and black dowel bar:
height 44 mm. – depth 17 mm.
– Hour-shape glass tensioning system to provide perfect fatness
– Cloth drops down from the front side of the housing at 12,5 cm. from the wall
– Screen housing available in different colours (optional)
